| Non
- Grain - Oriented electrical Steel |
| Grade |
Thickness |
Density |
Core Loss W/kg, max |
Induction T, min |
Lamination |
| mm |
g/cm2 |
W15/60 |
W15/50 |
B50(over) |
Factor%, min |
| 50A400 (S14) |
0.5 |
7.7 |
3.8 |
2.8 |
1.72 |
96 |
| 50A470 (S18) |
7.75 |
4.3 |
3.3 |
1.72 |
| 50A600 (S23) |
7.8 |
5.5 |
4.4 |
1.73 |
| 50A700 (S30) |
7.85 |
6.3 |
5.3 |
1.74 |
| 50A1300 (S60) |
7.9 |
8.2 |
6.5 |
1.75 |
|
|
|
| Grain
- Oriented electrical Steel |
| |
| |
| Grade |
Thickness |
Density |
Core Loss W/kg, max |
Induction T, min |
Lamination |
| mm |
g/cm2 |
W17/60 |
W17/50 |
B10(over) |
Factor%, min |
| 27P100 |
0.27 |
7.65 |
Less Than 1.29 |
Less Than 0.98 |
1.92 |
97 |
| 30P105 |
0.3 |
Less Than 1.36 |
Less Than 1.03 |
1.92 |
| 30G130 |
0.3 |
Less Than 1.62 |
Less Than 1.25 |
1.86 |
| 35G150 |
0.35 |
Less Than 1.91 |
Less Than 1.40 |
1.83 |
97.5 |
|
|
|
|
